Product Description:
Portable Media Player: Combine a portable TV with a media player
for watching movies and TV shows on the go.
Educational Tools: Integrate with educational content for mobile
teaching setups.
1. Display Size and Resolution
Resolution: Full HD resolutions include (1080p).
2. Power Source
Battery: Many portable TVs have built-in rechargeable batteries.
Check the battery life and charging options.
External Power: If you need longer use, consider options for
connecting to an external power source, like a USB power bank or an
AC adapter.
3. Inputs and Outputs
Video Inputs: Look for TVs with HDMI, AV, or USB inputs depending
on what you plan to connect (e.g., streaming devices, game
consoles).
Audio Output: If the TV has a headphone jack or Bluetooth
capability, it can be used for private listening or connecting
external speakers.
4. Portability Features
Mounting Options: Look for models with adjustable stands or
mounting options if you need to place the TV in
5. Connectivity
Wi-Fi/Bluetooth: For wireless connectivity options, which can be
useful for streaming content or connecting to other devices.
Technical Parameters:
| Panel Specification | Panel Size | 27inch |
| Product color | Black, White |
| LCD Panel Type | TFT LCD screen, LED black light, |
| Maximum resolution | 1920x1080 FHD, 16:9 Aspect Ratio |
| Display area(H / V) | 597.888x336.312mm |
| Dot Pitch(H / V) | 0.1038x0.3114 mm |
| Pixel Pitch (H / V) | 0.3114x0.3114 mm [81PPI] |
| Viewing Angle | H178°/V178° |
| Brightness | 350cd/m2 |
| Display color | 16.7M |
| Response time | 6ms |
| Contrast | 4000:1 |
| Life span | >60,000hours |
| Color system | PAL/NTSC/SECAM |
| Touch (optional) | Capacitive touch 10 points |
| Temepreted glass | 3.0-4.0mm (For protectiving LCD) |
Android 8.1-11 | CPU (optional) | RK3288 Quad Core, Cortex A-17 1.8GHz/RK3399 /RK3568 (optional) |
| Memory | 2GB/4GB DDR3 RAM (optional) |
| Storage(Option) | 16GB/32GB |
| Network card | 2.4G Wifi, Lan RJ45 / Bluetooth (Optional configuration sim card
4G/5G) |
| Output / Input | Output defualt, Input Optional |
| Interface | RJ45 *1, 2*USB 2.0, SD card solt*1, Power Interface, Power Switch |
| CMS | Supports pushing content and remote, management of unit, Or Not
optional |
| Battery | Battery cell type | Lithium iron phosphate cell battery,With protective circuit |
| Battery life | More than 3000 times cycles |
| Rated capacity | 230WH (Battery life 5 hours) |
| Standard Vol | 19.2V/5A (Max) |
| Charging port | DC 2.5mm |
| Maximum current | 24V/5A(Max) |
| Weight | 2.5kg |
| Wheels | Adjustable for height | 170mm |
| Angle | Rotation: clockwise 90°, counterclockwise 90°, Tilt: up 22° , and
down 22° |
| Wheels | 1inch Universal wheel |
Applications:
Meetings, Videos, Etc: Equipped with a front facing camera suitable for daily work and
life video needs, it can support screen mirroring.
Kitchen, Games, Music: Use landscape mode for movies, rotate it 90 degrees for social
media in portrait mode, or lay it flat in table mode for board
games and music.
Indoor Clothing Matching:Controlling the Portable Tablet TV is as easy as touching the
screen,making it simple for everyone in the family to enjoy.
Support and Services:
Q: What kind of inspection you can provide?
A: Zhongxin has multiple tests from material purchasing to finished
products by different departments, like QA, QC, sales
representative, to guarantee all signage players are in perfect
condition before shipment. We also accept the inspection by the
third party you appointed.
Q: What is your guarantee period?
A: Zhongxin provides 1 (one) year quality guarantee for the products
from your purchase date, except the human damage and force majeure
factor. For a better maintenance, be sure that the players are
using under normal circumstances (not more than 16 hours daily).
Beyond the guarantee period machine, Zhongxin will provide
maintenance service and technical support (Hardware and other
possible charges, we will not bear the responsibility)
Q: How can I pay for the order?
A: Our payment terms: T/T, Western Union, Paypal.
1) For sample order: 100% T/T or Western Union in advance, Paypal
is also acceptable.
2) For bulk order: T/T (Bank Transfer), 30% down payment, 70%
balance should be paid before the delivery of the goods.
