Product Description:
Aspect Ratio:The defining feature of a bar LCD screen is its ultra-wide aspect
ratio. This aspect ratio typically ranges from 16:3 to 32:9 or even
wider. The result is a long, slender display format that is
well-suited for showcasing content in unconventional layouts.
Brightness and Contrast: High brightness levels and contrast ratios to ensure excellent
visibility even in brightly lit environments. This makes them
highly suitable for a wide range of applications, including outdoor
signage, retail displays, and other scenarios where ambient
lighting conditions vary.
Custom Sizes: we offer our customers the flexibility to specify the exact
dimensions of their display to fit their specific needs.
Whether you require large-scale retail signage, transportation
displays, or industrial applications, we can custom-design displays
to fit your requirements. Our displays can be made to any size,
ensuring that you receive a solution that provides the best
performance and visual appeal.
Technical Parameters:
| Panel Parameter |
| Screen size | 23.1 inch | 35.5 inch | 47.1 inch | 49.5 inch |
| Screen type | TFT LCD Screen with LED back light |
| Resolution FHD (16:9) | 1920 x 158P | 1920 x 372P | 1920 x 540P | 1920 x 1080P |
| Brightness | 350cd/m2 | 350cd/m2 | 450cd/m2 | 450cd/m2 |
| Display Area(H/V)mm | 585.6 x 48.19 | 885 x 172 | 1152 x 324 | 1209.6x340.2 |
| Frame Size(H/V)mm | 587.4x60.4x16 | 921x 205.7x43 | 1192x364x40 | 1241.6x372.2x50 |
| Contrast Ratio | 4000 : 1 | 4000 : 1 | 4000 : 14 | 4000 : 1 |
| Display Colour | 16:7M(8bit) |
| View Angle (H/V) | 178°/178° |
| Response Time | 6ms |
| Life Time | 60000 Hrs |
| Operation system | Android OS 7 to 11 | Windows OS (WIN 7 to 10) |
| CPU Processor | Dual-core/Quad-core/Octa-core (optional) | Intel core i3 /i5 /i7 |
| Memory | 1GB /2GB/4GB/8GB (optional) | DDR3 4GB to Max 32 GB |
| Buit-in Storage | 8GB/16GB/32GB (optional) | SSD 128GB to 512 GB Max |
| Wifi / 4G / Lan | Yes | Yes |
| Port | RJ45, USB,HDMI Output, TF/SD card solt | RJ45, USB,HDMI /VGA output, DC-IN, LIN-OUT, MIC-IN |
| OTHERS |
| Frame material | Metal case(SPCC) |
| Colored System | PAL/NTSC/Auto-detecting |
| Speakers | 2×5W |
| Voltage | 100V-240V AC , 50/60Hz |
| Storage Temperature | '-20°C - 60°C |
| Storage Humidity | 10% - 95% no condensation |
Applications:
Connectivity: With several connectivity options that include HDMI, DisplayPort,
VGA, These connectivity options provide users with a wide range of
choices to connect their devices seamlessly with the stretched
display. With this capability, users can experience seamless
connectivity without having to switch from one screen to another.
Mounting Options: Stretched bar LCD screens are versatile in their orientations and
can be mounted in both landscape and portrait modes, depending on
the specific requirements of the application. This versatility
allows users to install these displays in a way that complements
their content, resulting in excellent user experience.
Picture Details:
FAQ:
Q: What kind of inspection you can provide?
A: Zhongxin has multiple tests from material purchasing to finished
products by different departments, like QA, QC, sales
representative, to guarantee all signage players are in perfect
condition before shipment. We also accept the inspection by the
third party you appointed.
Q: What is your guarantee period?
A: Zhongxin provides 1 (one) year quality guarantee for the
products from your purchase date, except the human damage and force
majeure factor. For a better maintenance, be sure that the players
are using under normal circumstances (not more than 16 hours
daily).
Beyond the guarantee period machine, Zhongxin will provide
maintenance service and technical support (Hardware and other
possible charges, we will not bear the responsibility)
Q: How can I pay for the order?
A: Our payment terms: T/T, Western Union, Paypal.
1) For sample order: 100% T/T or Western Union in advance, Paypal
is also acceptable.
2) For bulk order: T/T (Bank Transfer), 30% down payment, 70%
balance should be paid before the delivery of the goods.
