- Wall-mounted LCD display is to instation vertical surface on wall.
- Slim profile and lightweight construction, making them suitable for
easy installation on walls. They come in various sizes, from
compact screens for personal use to larger displays for public
viewing.
- Utilize Liquid Crystal Display (LCD) technology, providing
high-resolution visuals with vibrant colors and sharp imagery.
- Using mounting brackets or VESA-compatible mounts. This mounting
method ensures a secure and stable installation.
- offer a range of connectivity options such as HDMI, DisplayPort,
VGA, and USB ports. These ports allow for seamless integration with
multimedia devices like computers, media players, and cameras.
- Screen come with built-in control interfaces or remote control
devices for adjusting settings like brightness, contrast, volume,
and input sources. Adroid and Windows support network connectivity
for remote monitoring and management.
- can showcase various types of digital content including images,
videos, presentations, advertisements, and live feeds. They ensure
that content is displayed clearly and crisply, even from a
distance.
Features:
- High-Quality Displays: 1920x1080 FHD, 3840x2160 UHD
- Users can schedule content to play at specific times or dates,
allowing for targeted messaging and advertising based on time of
day or events.
- Interactive Touch Capabilities: support touch screens or other
interactive features, allowing users to engage directly with the
content being displayed.
- Support integrate with external data sources such as social media
feeds, weather updates, or news tickers to provide dynamic and
relevant content.
- Remote Monitoring and Diagnostics
- Multi-Zone Layouts: Digital signage displays can often be divided
into multiple zones, allowing users to display different types of
content simultaneously, such as advertisements, news updates, and
event schedules.
| LCD Panel Parameter |
| Style name | 49'' inch wall mounted lcd display |
| Support size | 15" to 110" |
| Type | TFT LCD SCREEN, LED BACK LIGHT |
| LCD Brand | BOE/LG/Samsung/Innolux/AUO etc. |
| Resolution | 1920 x 1080 FHD (16:9) 2K / 3840 x 2160 UHD (16:9) 4K |
| Display Area(H / V) | 1073.78(H) x 604(V)mm |
| Dot Pitch 2K/4K (H/V) | 0.1864×0.5592 mm/0.0932x0.2796 mm |
| Pixel Pitch 2K/4K (H/V)mm | 0.5592×0.5592 [45PPI]/0.2796x0.2796 [90PPI] |
| Brightness | 350-500cd/m2 |
| Contrast Ratio | 1200-3000 : 1 |
| Display Color | 16:7M(8bit) |
| View Angle (H / V) | 178°/178° |
| Response Time | 6ms |
| Tempered glass | 4.0mm (For protectiving LCD) |
| Touch Sensor | Infrared 10 points / Capcitive touch screen 10 points |
| Other Specifications Techical |
| Frame material | cold rolled steel sheet boday,aluminum alloy edge |
| Colored System | PAL/NTSC/Auto-detecting |
| Menu Language | Multiple language,English(Default) |
| Speakers | 2×5W |
| Noise Reduction | Yes |
| Voltage | 100V-240V AC , 50/60Hz |
| Life Time | 60000 Hrs |
| Power Consume (Max) | 78-118W |
| Working Temperature | 0°C~50°C |
| Working Humidity | 10% - 90% no condensation |
| Storage Temperature | -20°C - 60°C |
| Storage Humidity | 10% - 95% no condensation |
Function support | Android OS | Windows OS | Standalone Version |
| Android OS 7.0 to 11.0 | Windows 7/10 | V59 solution |
| TF/SD/USB | USB | SD card/USB 8GB |
| WIFI/RJ45 (5G/4G option) | WIFI/RJ45 (5G/4G option) | No network service |
| HDMI output,No HDMI input | HDMI & VGA output, No HDMI input | HDMI input,No HDMI output |
| Update contents by USB,or PC(Option) | Update contents by USB,or PC(Option) | Update contents by USB/SD |
| Infrared or capacitive touch(Option) | Infrared or capacitive touch(Option) | Touch is not supported |
| Support installing application | Support installing application | Application is not supported |
Applications:
Wall-mounted LCD displays are versatile and find applications in
various settings including retail stores, corporate offices,
healthcare facilities, education institutions, transportation hubs,
hospitality venues, and public spaces. They serve as effective
tools for digital signage, information display, and multimedia
presentations.
Overall, wall-mounted LCD digital signage provides a powerful
platform for delivering dynamic and engaging content in various
settings, including retail stores, corporate offices, restaurants,
transportation hubs, and public spaces.
Support and Services:
Our Digital signage lcd product comes with comprehensive technical
support and services to ensure your satisfaction:
- Phone and email support for any technical.
- Product installation and setup assistance
- Regular firmware updates to ensure optimal performance and
compatibility
- Remote troubleshooting and diagnostic services
- Extended warranty options for added peace of mind
FAQ:
Q: What kind of inspection you can provide?
A: Zhongxin has multiple tests from material purchasing to finished
products by different departments, like QA, QC, sales
representative, to guarantee all signage players are in perfect
condition before shipment. We also accept the inspection by the
third party you appointed.
Q: What is your guarantee period?
A: Zhongxin provides 1 (one) year quality guarantee for the
products from your purchase date, except the human damage and force
majeure factor. For a better maintenance, be sure that the players
are using under normal circumstances (not more than 16 hours
daily).
Beyond the guarantee period machine, Zhongxin will provide
maintenance service and technical support (Hardware and other
possible charges, we will not bear the responsibility)
Q: How can I pay for the order?
A: Our payment terms: T/T, Western Union, Paypal.
1) For sample order: 100% T/T or Western Union in advance, Paypal
is also acceptable.
2) For bulk order: T/T (Bank Transfer), 30% down payment, 70%
balance should be paid before the delivery of the goods.
