advertising Digital Signage Player used for restaurant menu boards
Features:
1. The 43" Advertising Player has wall mount, stand floor, indoor
outdoor touch no touch android windows versions,
2. We have two network version, the Android Operate System and the
Windows Operate System
3. The CPU of the Android Operate System has two configuration,
Quad-core, Hexa, Octa
4. The CPU of the Windows Operate System has several
configurations, Intel Intel I3/I5/I7
5. USB/SD/TF/MMC card is available to update and store the content
of the player,
6. PC is available to updated the content of all the ternminals,
7. Material support:
video(1080P),music,picture,txt,ppt,excel,word,pdf and webpage,etc
8. WIFI/ 5G/4G/Bluetooth is available to receive the newest update
everyday at any time;
9. The front of the player screen is covered with 9H tempered
glass, the frame is aluminum alloy, base is metal, rear panel is
cold roll steel sheet,
10. Touch screen is optional, touch sensor can be capacity and
infrared, normally default capacitive,touch surface is 9H tempered
glass
11. Automatic startup and shutdown , if there is no single input,
it will automatically enter the standby mode;
12. Vedio/Audio output: support CVBS Vedio output and the right and
left sound channel output;
13. Support a variety of vedio and image format;
14. The user can real-timely monitor the working condition of all
terminals through server (Real-timely grab any broadcast vedio,
pictures, captions of terminals,
15. Support split screen, such as video, logo, date, week, news,
weather, subtitles area, etc, and all of them can be displayed on
the terminal at the same time
| Panel Parameter |
| Panel Size | 43" |
| Model No | ZX-N243 |
| Panel Brand | LG/Samsung/AUO/BOE etc |
| Installation | Wall hainging digital signage, indoor |
| Panel Type | LCD screen & LED backlight |
| Standard Color | Black |
| Max Resolution (pixel) | 1920(RGB)*1080(FHD), 3840*2160 16:09 |
| Dot Pitch(mm) | 0.165*0.4845(W×H) |
| Display Color | 16.7M(8bit) |
| Brightness | 500cd/m2 |
| Contrast Ratio | 3000:1(Typical) |
| View Angle | 89°/89°89°/89°(Typical) |
| Response Time | 6ms(Typical) |
| Technical Specification |
| Frame material | Metal case, aluminum alloy frame,rear side cold roll steel sheet |
| Remote Controller | IR Remote Controller |
| Colored System | PAL/NTSC/Auto-detecting |
| Menu Language | Multiple language,English(Default) |
| Speakers | 2×5W |
| Noise Reduction | Yes |
| Voltage Frequency | 100V-240V AC |
| Horizon Frequency | 50/60Hz |
| Power Consume (Max) | ≤255W |
| Working Temperature | 0°C~50°C |
| Working Humidity | 10% - 90% no condensation |
| Storage Temperature | -20°C - 80°C |
| Storage Humidity | 85% no condensation |
| Operating System(Android for example) |
| Android CPU | Quad-Core |
| Memory | DDR3 2GB RAM, 8GB ROM |
| Update | USB/SD/WIFI/LAN/3G/4G |
| Touch sensor | capacitive/infrared /Non |
| Touch surface | 9H Anti-glare Tempered Glass |
| Difference between network and Basic version |
| Network Version | Basic Version |
| Android OS 11/Windows all in one Optional | Mstar solution |
| TF/SD/USB | SD/USB |
| WIFI/RJ45 (3G/4G option) | No network service |
| HDMI output | No HDMI output |
| HDMI/LVDS output (VGA option) | HDMI input |
| Update contents by USB/SD/WIFI/RJ232/PC/5G/4G | Update contents by USB/SD |
| Infrared or capacitive touch(Option) | Touch is not supported |
| Support software installing application | Application is not supported |
Q: What kind of inspection you can provide?
A: Zhongxin has multiple tests from material purchasing to finished
products by different departments, like QA, QC, sales
representative, to guarantee all signage players are in perfect
condition before shipment. We also accept the inspection by the
third party you appointed.
Q: What is your guarantee period?
A: Zhongxin provides 1 (one) year quality guarantee for the
products from your purchase date, except the human damage and force
majeure factor. For a better maintenance, be sure that the players
are using under normal circumstances (not more than 16 hours
daily).
Beyond the guarantee period machine, Zhongxin will provide
maintenance service and technical support (Hardware and other
possible charges, we will not bear the responsibility)
Q: How can I pay for the order?
A: Our payment terms: T/T, Western Union, Paypal.
1) For sample order: 100% T/T or Western Union in advance, Paypal
is also acceptable.
2) For bulk order: T/T (Bank Transfer), 30% down payment, 70%
balance should be paid before the delivery of the goods.
