LCD videowall, also known as a video wall, is a large display setup
comprised of multiple LCD (Liquid Crystal Display) panels
seamlessly tiled together to form a single, cohesive screen. These
videowalls are commonly used in various settings such as control
rooms, conference rooms, retail spaces, airports, stadiums, and
more, where large-scale visual displays are required.
The panels in an LCD digital singage are typically mounted
edge-to-edge, minimizing the bezels between them to create a
virtually uninterrupted viewing experience. This setup allows for
the creation of large-scale, high-resolution displays that can
showcase dynamic content such as videos, images, data
visualizations, and advertisements with clarity and impact.
Features:
1. Scalability: They can be customized to fit almost any size requirement by
adding or removing panels.
2. High resolution: With advancements in LCD technology, videowalls can achieve high
resolutions, providing sharp and detailed images even at close
viewing distances. and 3D comb filtering, digital noise reduction.
3. Flexibility: Content can be easily scaled and adjusted to fit the entire
videowall or specific sections of it, allowing for dynamic content
arrangements and layouts.
4. Brightness and color accuracy: LCD panels offer bright and vibrant displays with excellent color
reproduction, ensuring that content is visually striking even in
brightly lit environments.
5.Reliability: Modern LCD panels are designed for continuous operation, offering
high reliability and longevity.
6.LCD videowalls can be controlled and managed using specialized
software and hardware systems, allowing users to easily control
content playback, adjust settings, and monitor the status of
individual panels remotely.
| PANEL PARAMETER |
| Screen size | 55 inch |
| Screen type | LCD Screen with LED back light |
| LCD Brand | LG/Samsung/BOE |
| Super Narrow Bezel | 3.5mm | 1.8mm | 1.7mm | 0.88mm |
| Resolution FHD 16:9 | 1920 x 1080P | 1920 x 1080P | 1920 x 1080P | 1920 x 1080P |
| Brightness | 500cd/m2 | 500cd/m2 | 500cd/m2 | 500cd/m2 |
| Display Area(H/V)mm | 1209.6 x 680.4 | 1209.6 x 680.4 | 1209.6x 680.4 | 1209.6 x 680.4 |
| Dot Pitch(H/V)mm | 0.630 × 0.630 | 0.630 × 0.630 | 0.630 x 0.630 | 0.630 x 0.630 |
| Contrast Ratio | 1200-3000 : 1 | 1200-3000 : 1 | 1200-3000 : 1 | 1200-3000 : 1 |
| Display Colour | 16:7M(8bit) |
| View Angle (H/V) | 178°/178° |
| Response Time | <=6ms |
| Video Wall Controller(Built-in each Screen) |
| Digital signal input | HDMI×1； 1920x1080@60Hz backward compatible |
| Computer signal input | VGA(DB-15) ×1；1920x1080@60Hz backward compatible |
| Digital signal input | DVI(DVI-I)×1；1080P(1920×1080) backward compatible |
| Composite Video Input/(AV) | CVBS(BNC)x1 |
| Composite Video Output | CVBS(BNC)x1 |
| RJ45 | 3 or 4 |
| USB | 1(optional) |
| Computer centralized control interface | RS232 |
| OTHERS |
| Shell material | Metal shell |
| Installation way | Wall mount, floor standing mount,hanging mount |
| Power Supply | AC100V～240 |
| Power Consumption (Max) | 240W |
| Standby Power Consumption | <=3 |
| Working Temperature | 0°C~50°C |
| Working Humidity | 20% - 80% |
| Storage Temperature | -20°C - 60°C |
Applications:
Support and Services:
Our Digital signage lcd product comes with comprehensive technical
support and services to ensure your satisfaction:
- Phone and email support for any technical.
- Product installation and setup assistance
- Regular firmware updates to ensure optimal performance and
compatibility
- Remote troubleshooting and diagnostic services
- Extended warranty options for added peace of mind
FAQ:
Q: What kind of inspection you can provide?
A: Zhongxin has multiple tests from material purchasing to finished
products by different departments, like QA, QC, sales
representative, to guarantee all signage players are in perfect
condition before shipment. We also accept the inspection by the
third party you appointed.
Q: What is your guarantee period?
A: Zhongxin provides 1 (one) year quality guarantee for the
products from your purchase date, except the human damage and force
majeure factor. For a better maintenance, be sure that the players
are using under normal circumstances (not more than 16 hours
daily).
Beyond the guarantee period machine, Zhongxin will provide
maintenance service and technical support (Hardware and other
possible charges, we will not bear the responsibility)
Q: How can I pay for the order?
A: Our payment terms: T/T, Western Union, Paypal.
1) For sample order: 100% T/T or Western Union in advance, Paypal
is also acceptable.
2) For bulk order: T/T (Bank Transfer), 30% down payment, 70%
balance should be paid before the delivery of the goods.
