Product Description:
Our Touch Display Whiteboard is designed with an Aluminum Alloy
Frame, providing a sleek and modern look that will complement any
workspace or classroom. It is available with an optional OPS Slot
to support your OPS needs.
The LED/LCD Display has a Lifetime of 50000hrs, ensuring that you
get the best value for your investment. This Interactive Whiteboard
is perfect for any setting, whether you are in a classroom,
boardroom, or conference room.
Installation is made easy with our Wall Mounted option, and for
those who prefer mobility, our Mobile Stand option is also
available. This means that you can take your Interactive Whiteboard
wherever you need it, making it a versatile tool for all your
needs.
Our Multitouch Whiteboard Screen is perfect for group
collaborations, presentations, and lectures. It provides a seamless
writing experience, allowing multiple users to interact with the
screen simultaneously. This feature makes it easy to brainstorm
ideas, share presentations, and engage your audience.
Features:
- Product Name: Interactive touch screen whiteboard
- Screen Size: 55" 65" 75" 86" 98 Inches
- Support Ops: One OPS Slot (Optional)
- GPU: Mali-G51
- Material: SPCC+Aluminum Alloy Frame
- Lifetime: 50000hrs
- Features:
- Multitouch Whiteboard Screen
- Touch Display Whiteboard
- Multitouch Whiteboard Screen
- High resolution 3840x2160 This makes it perfect for displaying
detailed presentations, graphs, and images.
Technical Parameters:
| Display Information |
| Panel Size | 55inch, 65inch, 75inch, 86inch, 98inch, 100inch |
| Panel Type | a-Si TFT-LCD |
| Brand (Option) | BOE, LG, AUO |
| Aspect Ratio | 16:9,Wide SXGA |
| Max Resolution | 3840 x 2160 (UHD) @60hz, 4K UHD screen |
| View Angle | 178/178 |
| Brightness | 450-500cd/m2 |
| Display Colour | 8bit + FRC, (1.07 billion) |
| Contrast Ratio | 4000:01:00 |
| Response Time | 6ms |
| Surface Protection | Tempered Glass with 4mm thickness Standard |
| Whiteboard Type | Interactive Whiteboard |
| Infrared Touch |
| Sensing Type | Infrared touch (Multi 20 to 40 points) |
| Resolution | 32768x32768 , Number of infrared induction lines (W D) |
| Connection | Full-speed USB (Driver free) |
| Glass transmittance | > 88% (higher transmittance depends on glass surface treatment
technology such as AR/AG) |
| The light resistance | The light resistance |
| Speed of cursor | 8-12point/ms |
| Touch power supply mode | 5V USB, 0.5-2W |
| Built-in Dual System: Computer Part |
| Operating System | Android 9.1 to 11.0 | Windows 7/8/9/10 |
| CPU | ARM Cortex A73*2 and Quad-core A53*2 | I3/I5/I7Intergrated with CPU (The generation 4-10th) |
| GPU | Dual core Mali-G52 | |
| RAM | 4G DDR3 | 4G DDR /8G /16G |
| ROM Flash | 32G EMMC | 128G/256G SSD |
| Network | LAN, WIFI 2.4G, Bluetooth,4G/5G (Optional) |
| Video | All format, MPEG-1/2/4,AVS2 MP,H.264,H265,VP9 |
| Audio | MP3,AAC,WMA,RM,FLAC |
| HD video | 480i / 480p / 576i / 576p / 720p / 1080i / 1080p /2160p |
| Play mode | Power on,single card auto loop play;classified files auto loop
play;multi cards auto loop display etc |
| Port | USB2.0*2/ USB3.0*2/ HDMI out*1/ VGA out*1/ RJ45 Lan port*1/ Speaker
out*1/ Mic in*1 |
| Port of input | RJ45*1, VGA IN*1, VGA-AUDIO IN*1, Ypbpr IN*1, AV IN*1, RF-IN*1,
HDMI IN*2, USB 3.0*2, SD card slot*1, Touch USB*1, MIC*1, RS232*1 |
| Port of output | Spdif OUT*1, VGA OUT*1, Earphone*1, AV OUT*1, |
| Front I/O | USB 2.0*1, HDMI *1, ouch USB*1 |
| Languages | English, French, Germany, Arabic, Italian, Japanese,Korean,
Russian, Spanish, etc |
| Speaker | 2x5W(built in) |
| Power Supply | 100-240VAC 50/60HZ |
| Standby power Watts | <270W |
| Temperature | Working temperature: 0°C~50°C, Storage temperature: ,20°C - 60°C |
| Humidity | Working humidity: 20%~80%(No condensation), Storage humidity: Storage humidity |
| Accessories | AC Power Cable, 4-in-1 Remote Control, Touch Pens*1, whiteboard
software |
Applications:
The multitouch whiteboard screen is perfect for educational and
business purposes, making it an ideal solution for schools,
universities, conference rooms, and corporate offices.
The Interactive Whiteboard is its versatility. It can be used in a
variety of situations, including classrooms, boardrooms, training
sessions, and more.
The whiteboard is also very easy to install and comes with all the
necessary hardware and software. This ensures that you can start
using it right away without any hassle.
Support and Services:
Our Interactive touch screen whiteboard product comes with
comprehensive technical support and services:
- Initial setup and installation assistance
- Remote technical support for troubleshooting and problem-solving
- Regular software updates and maintenance to ensure optimal
performance
- Warranty coverage for hardware and software malfunctions
- Optional extended warranty and service plans for added protection
Packing and Shipping:
Product Packaging:
The Interactive Touch Screen Whiteboard will be packaged securely
in a sturdy cardboard box to ensure it arrives in perfect
condition. The box will be labeled with the product name,
description, and handling instructions.
Shipping:
The product will be shipped via a reliable courier service with
tracking information provided to the customer upon shipment.
Shipping time will vary depending on the customer's location, but
we strive to deliver within 3-5 business days.
